Description
The 10-inch FIG 500 ACME THREAD Air Mover Adapter is precision-machined from high-strength 6061 aluminum to provide a secure, reliable connection between standard 10-inch FIG 500 blow-off connections and venturi-style air movers. Engineered for maximum airflow capacity, this adapter can be configured to accept 8-inch or 10-inch air movers based on operational requirements, delivering powerful, controlled ventilation for large-diameter pipeline operations.
Key Features
- 6061 Aluminum Construction – Lightweight, durable, and corrosion-resistant for demanding field conditions
- Secure Mechanical Fit – Eliminates the need for unsafe attachment methods such as straps or tape
- Leak-Resistant Seal – Maintains consistent airflow and reduces risk of air intrusion
- Configurable Outlet Options – Designed to accept 8″ or 10″ venturi-style air movers
- Maximum Airflow Performance – Ideal for high-volume ventilation in large-diameter pipelines
- Field-Proven Design – Built by a pipeline operator for real-world applications
- Intrinsically Safer Material Choice – Non-ferrous construction suited for hazardous environments
Applications
- Large-diameter pipeline hot cuts
- Tie-ins and weld repairs requiring maximum airflow
- Blowdowns and controlled venting
- Compressor station maintenance and scrubber filter changeouts
Specifications
- Pipeline Connection: 10″ FIG 500 ACME THREAD
- Air Mover Connection: Configurable (8″ or 10″)
- Material: 6061 Aluminum
- Finish: Machined / Optional anodized
- Sealing Method: Integrated O-ring groove with compression seal
- Hardware: Stainless steel fasteners
Lead Time
Typically 6–8 weeks depending on order volume and configuration
Typically 6–8 weeks depending on order volume and configuration
Important Notice
This product is designed for temporary use during controlled pipeline operations only. Always follow company procedures, applicable safety standards, and proper gas monitoring practices when in use.
